Manual Refilling Pump MFP
Clean refilling of lubrication pumps and lubricant cartridges
The MFP is a manual refilling pump specifically designed for applications with NLGI grade 0 to 2 greases. It is intended for use with 18 kg barrels or buckets with or without follower plate. Follower plate is essential to ensure reliable suction and optimal emptying of the barrel while using hard greases. This pump is fitted with a 2-metre long high-pressure hose that features a quick coupling female connector compatible with SKF filling filter often found in SKF Lincoln automatic lubrication system pumps. Additionally, an adaptor for filling Lube-Shuttle cartridges is available as an option. The MFP dispenses a volume of 25 cm³ per stroke and operates at pressures of up to 60 bar. Two versions of the MFP are available, each tailored for different NLGI grades of lubricants. This market-proven solution, tested under the harsh conditions of Nordic winters, is noted for its high reliability, durability, and ease of use.
Features & benefits
- Market proven design
- Fast to install and easy to use
- Most reliable also under harsh condition
- Fluid grease and grease design versions available
Applications
- MMPC machinery
- Forestry machines
- Construction vehicles
- Utility service vehicles
- Breakers and hammers
- Lifting and telehandlers
- Agriculture vehicles,
- machines, attachments
Technical Data
| Function principle | manually operated refilling pump | |
| Lubricants | fluid grease and grease up to NLGI grade 2 | |
| Number of outlets | 1 | |
| Metering quantity per outlet | 25 cm³/stroke | 9.84 in3/stroke |
| Suitable barrel sizes | 18 kg (1/8 barrel) | |
| Operating temperature | –30 to +55 °C | –22 to 130 °F |
| Operating pressure | max. 60 bar | 70 psi |
| Hose lengths | 2 m | 6.5 ft |
| Hose end thread | G1/4 | |
| Coupling | female 2500 series QC | |
| Materials | ||
| Pump body | zinc plated steel | |
| Follower plate | steel plate, POM, NBR | |
| Lid | painted steel | |
| Lid fixing | POM | |
| Suitable barrel diameters | min. 270 mm | min. 10.63 in |
| max. 300 mm | max. 11.8 in | |
| Dimensions (without follower plate) | 550 × 380 × 320 mm | 21.65 × 14.96 × 12.59 in |
| Weight (without follower plate) | 7 kg | |
| Operating position | upright |
Order Informaation
| 11600330 | SKF manual filling pump for NLGI 000-0 fluid grease (18 kg barrels) |
| 11600340 | SKF manual filling pump for NLGI-2 grease incl. follower plate (18 kg barrels) |
| 11770464 | Lube-Shuttle cartridge filling adapter for MFP pump |
